| Main Feature |
| | |
| Lens | 20x f4.42mm ~ 88.5mm F1.8 ~ F2.8 |
| Horizontal FOV | 60.7° ~ 3.36° |
| Vertical FOV | 34.1° ~ 1.89° |
| | |
| Video Output Specification | |
| HD Output | 1 x HDMI: Version 1.3; 1 x 3G-SDI: BNC 800mVp-p 75Ω (SMPTE 424M standard) |
| Video Compression | H.264 |
| Signal System | HDMI, 3G-SDI: Supports various frame rates and resolutions up to 1080p60 |
| | |
| Camera Performance | |
| Sensor | 1/2.8 inches CMOS, 2.07 Megapixels |
| Scanning Mode | Progressive |
| Minimum Illumination | 0.5Lux @ (F1.8 AGC ON) |
| Shutter | 1/30s ~ 1/10000s |
| White Balance | Auto, Indoor, Outdoor, One Push, Manual, VAR |
| Backlight Compensation | Support |
| Digital Noise Reduction | 2D & 3D Digital Noise Reduction |
| SNR | ≥ 55dB |
| | |
| Pan/Tilt Specification | |
| Pan Angle | ±170° |
| Tilt Angle | -30° ~ +90° |
| Pan Speed | 1.7° ~ 100° /s |
| Tilt Speed | 1.7° ~ 69.9° /s |
| Image Flip | Support |
| Image Freeze | Support |
| Preset Position | 255 |
| Preset Accuracy | 0.1° |
| | |
| Audio Specification | |
| Microphone Array | Built-in dual microphones, 100Hz to 16KHz frequency response |
| Analog Audio I/O | Support 3.5mm Line-In; Support 3.5mm Line-Out |
| Digital Audio Output | Support HDMI, USB, LAN, 3G-SDI, etc. |
| | |
| Control Interface | |
| RS485 | 2pin phoenix port, Max Distance: 1200m, Protocol: VISCA / Pelco-D / Pelco-P |
| RS232 IN | 8pin Mini DIN, Max Distance: 30m, Protocol: VISCA / Pelco-D / Pelco-P |
| RS232 OUT | 8pin Mini DIN, Max Distance: 30m, Protocol: VISCA only |
| | |
| Network Specification | |
| Protocols | FULL NDI, NDI |
| | |
| Power & Environmental Specification | |
| Input Voltage | DC 12V / PoE+ (802.3at) |
| Input Current | 1.5 A (Max.) |
| Operating Temperature | 0° C ~ 40° C |
| Storage Temperature | -40° C ~ 60° C |
| Power Consumption | 15W (Max.) |
| | |
| Physical Specification | |
| Dimension | 169mm × 142mm × 175mm |
| Net Weight | 1.5kg |
